Alien_X · « **on:** April 08, 2009, 11:31:17 AM »

Hello acidmods

I am in the middle of finalizing my design for a PSP 1000 Dpad Breakout board. This will allow you to easily solder / piggyback the individual dpad button signals. It will be quick to install,low profile and easy to solder wires to.

Installation will only require you to file down part of the topside of the PCB and then insert into the Zif (ribbon) connector on the motherboard. The pcb wraps around the connector, fitting into unpopulated space of the motherboard. This design does not use fpcs and does not take up any space under the daughterboard. This simple circuitboard will allow you to build external controllers, analog controlled dpads and many many more peripherals without any soldering to the 0.5mm pitch zif connector. The item would be priced at around $10 to $15 and come preassembled. By following the installation manual you could be up and running in a matter of minutes!

Without further ado here are some previews:

Bottom:

Top:

I am hoping for this item to be sold through Sparkfun.com, and to aid with my market research, if you would be interested in such a product or have any thoughts or comments then please post in this thread.

Thanks.

atomicareprise · « **Reply #1 on:** April 08, 2009, 11:33:47 AM »

that's nice alien...soldering will be a breeze...

DubbleDutch · « **Reply #2 on:** April 08, 2009, 11:34:55 AM »

as i said on msn

this will make it a lot easier for people to do the external controller mod!

DarkShot · « **Reply #3 on:** April 08, 2009, 11:44:06 AM »

Breakout boards FTW

Great job Alien.

Now we need something like that for the slim.

Alien_X · « **Reply #4 on:** April 08, 2009, 11:49:36 AM »

Thanks for the positive comments so far. However I can only bring this product to market if there is sufficient interest in the product, so along with your comments please could you post whether you would be seriously interested in purchasing one of these items for the aforementioned price.

Thanks again
Alien

treemty · « **Reply #5 on:** April 08, 2009, 12:12:32 PM »

I would seriously be interested in this

I wonder if you could make one for the ABXY area as well, as it would make installation for dual nubs easy for people who are not that goo at soldering

PhenomenalDesigns · « **Reply #6 on:** April 08, 2009, 12:26:30 PM »

Nice, I think you should make one for the ABXY like treemty said, since many more people try to do the dual nub compared to external controler

Although I am quite interested in this

Alien_X · « **Reply #7 on:** April 08, 2009, 12:39:44 PM »

Okay I will take that into consideration, thanks.
I think that the main reason people do not try the external controller is because they cannot solder the connector (Which isn't that hard if you have a microscope

)

If a person cannot solder the ABXY points for the dual nub, they surely wouldn't be able to solder the wires to the razor either, so there isn't too much point, especially for the psp 1000.

Tri-edge · « **Reply #8 on:** April 08, 2009, 01:05:48 PM »

if you can do this for the slim I would buy it in a heartbeat.

Alien_X · « **Reply #9 on:** April 08, 2009, 02:05:46 PM »

Okay, this product isn't for the slim, and as such it won't work on a slim.
I don't own a slim and do not plan to create a pcb for one person.

At the moment there only appears to be serious interest from two people, I thought more people would want an item like this! If there isn't any more interest from members of this community then it would probably be in my best interest to abandon this entirely.

Alien out

DarkShot · « **Reply #10 on:** April 08, 2009, 02:08:47 PM »

Quote from: Tri-edge on April 08, 2009, 01:05:48 PM

if you can do this for the slim I would buy it in a heartbeat.

Absolutely my exact thoughts as well.

Perhaps an alteration of the design to accompany the slim would be better, for the slim is more recent, and to my understanding, the pinout of the 3000 is also the same as 2000.

Many more people could try doing dual nub to the 2000 and 3000, which might actually make it more popular.

Not to mention, It does take time for good ideas to catch on.

Tri-edge · « **Reply #11 on:** April 08, 2009, 05:03:23 PM »

Quote from: Alien_X on April 08, 2009, 02:05:46 PM

Okay, this product isn't for the slim, and as such it won't work on a slim.
I don't own a slim and do not plan to create a pcb for one person.

I know it's not for the slim, I'm just saying if you make one for the slim that I would buy it (and a bunch of other people would too)

Quote from: Alien_X on April 08, 2009, 02:05:46 PM

At the moment there only appears to be serious interest from two people, I thought more people would want an item like this! If there isn't any more interest from members of this community then it would probably be in my best interest to abandon this entirely.

Alien out

I would buy it if I still have my phat. If you release this I might go get a phat just to try this out

bustinthejustin · « **Reply #12 on:** April 08, 2009, 07:01:02 PM »

I have a fat, but I would never mod it. However, if I did have a phat, I would definitely buy this to try an external controller. One for the slim would have more interest though

GhoSt · « **Reply #13 on:** April 08, 2009, 10:05:44 PM »

thats cool, got the altium files for it?

MARIOPARTY53 · « **Reply #14 on:** April 08, 2009, 10:44:25 PM »

dude, i sooooooooooooooooo need this, i will probaly buy one

thats really great

i really hope this comes out

Alien_X · « **Reply #15 on:** April 09, 2009, 12:16:59 AM »

Quote from: GhoSt_Death on April 08, 2009, 10:05:44 PM

thats cool, got the altium files for it?

Sorry, I designed this in eagle and it isn't open source.

Quote from: MARIOPARTY53 on April 08, 2009, 10:44:25 PM

dude, i sooooooooooooooooo need this, i will probaly buy one

thats really great i really hope this comes out

It's cool that you're interested, but with this amount of interest I doubt whether it will happen.

ApheX · « **Reply #16 on:** April 09, 2009, 01:49:38 AM »

mate, i'll buy one if it's released. I also agree with the idea of making one for the slim, i think you would have more people interested with a 2000 version.

Alien_X · « **Reply #17 on:** April 09, 2009, 02:04:53 AM »

Okay, well with the current interest so far I don't think it will be possible to have sparkfun sell this item on my behalf. However I am going to put in an order with the PCB fab house for one (for myself to test out), if anyone would like to me to order a prototype for them along with mine then please PM me - the board will be $9.5 + postage (usually around 50p to almost any country). This will be just the bare PCB, so a connector will have to be soldered on by yourselves.

If anyone who owns a psp slim would like to work with me to develop a connector then I would happily oblige.

PhenomenalDesigns · « **Reply #18 on:** April 09, 2009, 03:01:10 AM »

Would it be like a ribbon or an actual PCB?

Alien_X · « **Reply #19 on:** April 09, 2009, 03:08:22 AM »

A fabbed pcb from same manufacturer as this -

atomicareprise · « **Reply #20 on:** April 09, 2009, 07:21:30 AM »

well you're doing the d-pad why not do the abxy as well budy...

that will make it even...i'm also interested in this mod so i hope to see this product

sooner or later...doing external controller will now be much easier..

EliteGamer83 · « **Reply #21 on:** April 09, 2009, 12:00:18 PM »

I would buy it if it was for slim.

GhoSt · « **Reply #22 on:** April 09, 2009, 03:46:19 PM »

Quote from: atomicareprise on April 09, 2009, 07:21:30 AM

well you're doing the d-pad why not do the abxy as well budy...

that will make it even...i'm also interested in this mod so i hope to see this product

sooner or later...doing external controller will now be much easier..

because mos't people have the ability to solder to the Powerboard, and alot cannot solder wires to a 0.5mm pitch zif connector.

EliteGamer83 · « **Reply #23 on:** April 09, 2009, 05:18:57 PM »

Seriously you will need to make one for the slim with the D-pad and abxy. I asked jumbo and he wants me to pay him $30 just to do this. I'd rather pay $30 for this for d-pad and abxy then pay jumbo for something that with things can happen, like the wires could pop off in the mail and then what?

rceckspurt13 · « **Reply #24 on:** April 09, 2009, 08:07:51 PM »

I'd say if it breaks in the mail, you send it back with a nice note explaining what happened and ask for it to be fixed. I'm sure you could get it re-done.

EliteGamer83 · « **Reply #25 on:** April 09, 2009, 08:11:24 PM »

Quote from: rceckspurt13 on April 09, 2009, 08:07:51 PM

I'd say if it breaks in the mail, you send it back with a nice note explaining what happened and ask for it to be fixed. I'm sure you could get it re-done.

I mean still even thatt, like if I acedently break it off during modding or sometmes in the future if jumbo leaves AM or whoever I get to do it. I'd much rater have something I can hold in my own hands and do myself.

Alien_X · « **Reply #26 on:** April 10, 2009, 01:23:45 AM »

Quote from: EliteGamer83 on April 09, 2009, 08:11:24 PM

I mean still even thatt, like if I acedently break it off during modding or sometmes in the future if jumbo leaves AM or whoever I get to do it. I'd much rater have something I can hold in my own hands and do myself.

You want to know the solution to that? - Learn to solder

There isn't going to be a slim version from me.

This project can now be considered abandoned. To everyone who mentioned "slim" in this topic, I personally hate you.

Good bye

ApheX · « **Reply #27 on:** April 10, 2009, 02:24:15 AM »

Quote from: Alien_X on April 10, 2009, 01:23:45 AM

You want to know the solution to that? - Learn to solder

There isn't going to be a slim version from me.

This project can now be considered abandoned. To everyone who mentioned "slim" in this topic, I personally hate you.

Good bye

Don't be like that Alien. You did ask us to post here if we were interested in this product. You were bound to get people asking for a similer version for the slim, what did you expect.

Alien_X · « **Reply #28 on:** April 10, 2009, 04:19:18 AM »

I am just annoyed as I spent a long time designing this for others, not myself.

I have decided to take some pictures of my process for soldering the PSP 1000 ABXY, since that seems slightly more popular. They can be found Here along with pictures of "The perfect joint".

EliteGamer83 · « **Reply #29 on:** April 10, 2009, 07:28:22 AM »

Oh so now it's MY fault? All I said it "You should make one for slim" what's wrong with that!? you asked for feedback! now your flaming me just because I said it would be nice for slim!? you have anger issues dude... seriously =|

Alright who gave me another -
