Author Topic: Tracey's new xbox (Read 6225 times)

Modded Matt · « **on:** August 14, 2011, 05:32:00 PM »

http://www.youtube.com/watch?v=cg1H0ZjoCHU

One of our members recently made a pink xbox with a playboy bunny cut out. My wife loved this so much I had to make her one. I am sorry I did not take any pics of the cutting process, but I will try to document the mod from here forward, and bring you up to speed.

I printed a playboy bunny head enlarged to fill a 8x11 sheet of paper, I then cut the image out carefully only making one cut into the boarder so I can use the outline as a stencil.

The 8x11 paper centers on the case very well, its almost the exact width and fits between the holes vertically helping to center and align your image. I secured the paper to the case using thin strips of tape (so it dosnt cover too much if the actual image) but be sure to use enough pieces that will keep paint from getting under the stencil. Then I painted the case, nothing fancy, just transferring the image.

I then removed the stencil and used my dremmel to cut out the image. when I cut the image out of the case, I want to make sure to keep control of the dremmel to i dont over cut anything and create more work for myself later. When cutting the image, start from the center and cut the image out, leaving a small outline of the painted image.

After the piece is cut, I then took the sanding wheel of my dremmel and finished it off, you want keep the sanding wheel moving around the part (not sitting in one place) sand a whole section at a time, this will make smoother lines. Get as much as you can with the tool SAFELY, you dont want to over cut your image. Finish cleaning the cuts using a 60-80 grit sand paper by hand, use a flat bastard file for the straight areas.once you have your cut shaped the way you like, polish it off with a lighter grit sand paper to smooth the scratches.

Now you need to inspect the back side of the case, remove any of the support molds that will obstruct your window pane. (I use a 8x11 sheet of 1/8 inch lexan I got from lowes for like $1.99 it has a protective sheet on each side to keep from scratching) once you have it fit so it lies completely flat at all areas, lay your window to the side and prep your shell for paint.

find a clean dry place that will ventilate and protect your work from any bugs or dust that may be in the air. I use a scuffing pad to take the shine off the plastic shell and allow for better paint adhesion. use a degreaser, or rubbing alcohol to clean any contaminates from the shell (make sure not to touch the surface with your skin after cleaning(oils)) allow to dry and paint according to paint instructions.

once the paint has fully cured, glue your window inside the shell making sure not to allow glue to squeeze out onto your window or shell. I used 5 min epoxy for mine. clean everything up and get ready for leds and reassembly....another day.

Before you ask:
the eye is just a piece of tape I stuck there, and the protective paper is on the window still.

[gmod]resized those pics as it was bringing up a scroll bar, GhoSt[/gmod]

final video:

http://youtu.be/cg1H0ZjoCHU

1TONpete · « **Reply #1 on:** August 14, 2011, 05:35:45 PM »

Coming along great Matt bet tracy's happy. Great job. Cant wait to see it all lit up.

Rodent · « **Reply #2 on:** August 14, 2011, 05:39:59 PM »

Nice Job congrates on such a nice xbox also , Tracy gotta be in love with that thing, what color pink did you use floresent pink? looks Badass with the black

Monk3y · « **Reply #3 on:** August 14, 2011, 05:42:56 PM »

Looks pretty nice, loving the hot pink :P

hyper999 · « **Reply #4 on:** August 14, 2011, 05:53:55 PM »

Even painted the drive cables lol

kronosslayer · « **Reply #5 on:** August 14, 2011, 05:59:22 PM »

Sexah!!!

That's some killer Dremel work,Great work!!!

I would love to get my girlfriend an Xbox like that!!

But first things first, i need the girlfriend

robin1989 · « **Reply #6 on:** August 14, 2011, 06:42:44 PM »

thats v.nice - my sister would love that

loboplayero · « **Reply #7 on:** August 14, 2011, 07:42:14 PM »

not for nothing im not a girl but i will trully rock this xbox

this baby its going to look good

i love the way that playbunny looks!

Modded Matt · « **Reply #8 on:** August 20, 2011, 01:28:47 PM »

ok so minor set back today, I wired up my "pink" led's and they are like a dull pink so they clash with the hot pink I painted. so Im off to find new paint. but me and the wife argue about the shade so I have to rig up a "flashlight" lol to make sure I get the best match. I also noticed I have an area that needs to be lit better so I am going to add another led or two.

Ill post some new pics tonight

PsychoticWolf · « **Reply #9 on:** August 20, 2011, 06:08:47 PM »

Quote from: modded matt on August 20, 2011, 01:28:47 PM

ok so minor set back today, I wired up my "pink" led's and they are like a dull pink so they clash with the hot pink I painted. so Im off to find new paint. but me and the wife argue about the shade so I have to rig up a "flashlight" lol to make sure I get the best match. I also noticed I have an area that needs to be lit better so I am going to add another led or two.

Ill post some new pics tonight

Can't wait to see. That looks pretty cool, I mean the way it looks is just stylish awesome job Matt.

Modded Matt · « **Reply #10 on:** August 21, 2011, 04:12:43 PM »

Ok I finished the xobox today. I cant get the you tube video to embed.

http://youtu.be/cg1H0ZjoCHU

I also posted the full story on my blog:

http://blogs.acidmods.com/moddedmatt/2011/08/21/traceys-new-xbox-360/

crazy-modder · « **Reply #11 on:** August 21, 2011, 04:20:31 PM »

Matt that xbox is REALLY nice!! came out super clean and the led mod is pretty sweet. What code did you use for that?

Modded Matt · « **Reply #12 on:** August 21, 2011, 04:27:15 PM »

thanks,

that is the abxy chaser by topbuzz, its in the free code list

Rodent · « **Reply #13 on:** August 21, 2011, 04:27:25 PM »

Awsome job Matt, love the led modes, and the colors show up great too

Guess shes pretty happy about it also Nice work!!!!!

whitetop · « **Reply #14 on:** August 21, 2011, 04:43:18 PM »

that is sexy man you got some skills there

Hazer · « **Reply #15 on:** August 21, 2011, 05:39:09 PM »

SWEET.

Quote

Ok I finished the xobox today. I cant get the you tube video to embed.

I had the same problem. What I do is copy the address when viewing the youtube page and paste that in the regular url link tabs.

Modded Matt · « **Reply #16 on:** August 21, 2011, 05:39:52 PM »

http://s370.photobucket.com/albums/oo142/moddedmatt/?action=view&current=video-2011-08-21-16-11-38.mp4

thats the tool I used to match the leds to the paint in the store

Modded Matt · « **Reply #17 on:** August 21, 2011, 05:50:24 PM »

Quote from: Hazer on August 21, 2011, 05:39:09 PM

SWEET.

I had the same problem. What I do is copy the address when viewing the youtube page and paste that in the regular url link tabs.

yep that worked standard url bbc code using the acctual address works!!
top post updated

1TONpete · « **Reply #18 on:** August 22, 2011, 03:21:39 AM »

Great Job Matt. I love the combo. I and I love the "Rooster"- one of my top 10

Rodent · « **Reply #19 on:** August 22, 2011, 03:52:16 AM »

Quote from: modded matt on August 21, 2011, 05:39:52 PM

http://s370.photobucket.com/albums/oo142/moddedmatt/?action=view&current=video-2011-08-21-16-11-38.mp4

thats the tool I used to match the leds to the paint in the store

AWSOME TOOL, I can imagine the look on everyones face when you were walking around with a led light to match the paint.....LOL... Great Idea though. ....Nice work

1TONpete · « **Reply #20 on:** August 22, 2011, 04:03:02 AM »

Funny but true story: I had a very similar tool , for a totally different purpose. So my son got a Lego stuck up his nose... turned out to be a Lego man hand. I couldn't see up his nose very well , to tell if he had something up there or he just had a runny nose or something. (find out if I gotta go to ER or not) So what i did was exactly that only I used a 3mm white led, which had a lil blue in it and made things a lil weird. But the tool looked exactly the same. So the short end to the story:
We go to the ER and are just about to see the Dr. when , he finally sneezes the lil hand out right into my lap. and we go home and stories over... or not
So about a week goes by and my daughter starts having nasal issues and then , I grab my handly lil LED tool and look up there and there is something in there but I can't tell what it is , but I think its a lego head and its stuck. So off to the Dr again. This time I was able to see her regular Dr. and he ended up pulling out (very gently and with great bedside manners btw) ....... a huge un-popped popcorn kernel.

Anonamous · « **Reply #21 on:** August 22, 2011, 07:16:04 AM »

Nice, so now what about the matching controller to go with it? Black controller with pink thumbsticks pink bumpers an triggers, and pink leds yes?

NicxCustoms · « **Reply #22 on:** August 24, 2011, 01:55:25 PM »

I really like how the leds are activated....nice

ßß

nEoVaLoR · « **Reply #23 on:** August 24, 2011, 02:13:25 PM »

Quote from: 1TONpete on August 22, 2011, 04:03:02 AM

Funny but true story: I had a very similar tool , for a totally different purpose. So my son got a Lego stuck up his nose... turned out to be a Lego man hand. I couldn't see up his nose very well , to tell if he had something up there or he just had a runny nose or something. (find out if I gotta go to ER or not) So what i did was exactly that only I used a 3mm white led, which had a lil blue in it and made things a lil weird. But the tool looked exactly the same. So the short end to the story:
We go to the ER and are just about to see the Dr. when , he finally sneezes the lil hand out right into my lap. and we go home and stories over... or not
So about a week goes by and my daughter starts having nasal issues and then , I grab my handly lil LED tool and look up there and there is something in there but I can't tell what it is , but I think its a lego head and its stuck. So off to the Dr again. This time I was able to see her regular Dr. and he ended up pulling out (very gently and with great bedside manners btw) ....... a huge un-popped popcorn kernel.

hahahahahaha!! can't wait til i have kids... NOT

PsychoticWolf · « **Reply #24 on:** August 26, 2011, 03:00:03 AM »

Quote from: modded matt on August 21, 2011, 05:39:52 PM

http://s370.photobucket.com/albums/oo142/moddedmatt/?action=view&current=video-2011-08-21-16-11-38.mp4

thats the tool I used to match the leds to the paint in the store

Hey that kinda looks like my det---I mean something I made cause I didn't have a flashlight one night so i used what I had lol Bright White LEDs for the win.
