Author Topic: Project (Read 5931 times)

Alien_X · « **on:** October 18, 2008, 03:27:20 AM »

Thanks to Blizzrad

I will do the rest when my lcds from steveo arrive, and when my drill has charged up

Paper makes the coolest photo backgrounds

PspKicks316 · « **Reply #1 on:** October 18, 2008, 06:44:10 AM »

Paper does make cool photo backgrounds

But holy crap, that's coming along quite nicely!!!! It looks so awesome! I don't know why, it just LOOKS and screams awesome. I love it!

Alien_X · « **Reply #2 on:** October 18, 2008, 10:10:48 AM »

Thanks, now the screen and lcd cage are screwed and mounted.

Pics later, I am working on something for cyber at the moment.

MARIOPARTY53 · « **Reply #3 on:** October 18, 2008, 07:48:36 PM »

i dont get it

Tri-edge · « **Reply #4 on:** October 18, 2008, 08:23:51 PM »

Quote from: MARIOPARTY53 on October 18, 2008, 07:48:36 PM

i dont get it

I think he's making a breakout board for everything on the psp slim.

Jumbo · « **Reply #5 on:** October 18, 2008, 08:46:59 PM »

Quote from: dslitemodder on October 18, 2008, 08:23:51 PM

I think he's making a breakout board for everything on the psp slim.

PSP Phat

Looking greater every day (Duh!)

The finished piece will definitely be amazing!

GhoSt · « **Reply #6 on:** October 18, 2008, 08:55:08 PM »

Quote from: dslitemodder on October 18, 2008, 08:23:51 PM

I think he's making a breakout board for everything on the psp slim.

yea.

I think its a awesome idea, allows you to have plug and play action with every single thing inside the psp through the breadboards.

And also its just awesome, as Kicks said in the old topic "PSP ART"

MARIOPARTY53 · « **Reply #7 on:** October 18, 2008, 11:59:18 PM »

it atill doesnt make sense to me

Its not even psp any more

Its pswa
Play station wall art

Alien_X · « **Reply #8 on:** October 19, 2008, 01:00:26 AM »

Quote from: MARIOPARTY53 on October 18, 2008, 11:59:18 PM

it atill doesnt make sense to me Its not even psp any more

Its pswa
Play station wall art

Haha, I guess you could think of it like that.

[insert rude comment about your snesp here]

Tri-edge · « **Reply #9 on:** October 19, 2008, 10:44:10 AM »

but now the real question arises. What are you planning on doing with it when your done?

Alien_X · « **Reply #10 on:** October 19, 2008, 10:56:16 AM »

Quote from: dslitemodder on October 19, 2008, 10:44:10 AM

but now the real question arises. What are you planning on doing with it when your done?

Haha, Well first I am going to attempt to get tv out working, and wire up/mount a dsub connector and shroud for the vga output.
And then the second thing will be something for cyber.

SN!P3R · « **Reply #11 on:** October 19, 2008, 11:15:01 AM »

are you gonna put the abxy and dpad on as well?

Alien_X · « **Reply #12 on:** October 20, 2008, 03:19:50 AM »

Quote from: PSPHax0r on October 19, 2008, 11:15:01 AM

are you gonna put the abxy and dpad on as well?

Yeah, they will be interfaced with an array of tact switches, and a ps2 controller.

Ribbons Arrived, so I will get this finished very very soon

m@DDm!k3 · « **Reply #13 on:** October 21, 2008, 10:40:10 PM »

Thats gonna be ultimate keep up the good work man

Alien_X · « **Reply #14 on:** October 22, 2008, 01:46:18 AM »

Quote from: m@DDm!k3 on October 21, 2008, 10:40:10 PM

Thats gonna be ultimate keep up the good work man

okay second update..

I knocked a glass of water off a high shelf onto the motherboard, so my replacement is arriving today.
Secondly, my parts from farnell are arriving today, so I should get it finished ASAP.

I am also picking up a laser printer, and a laminator today. + karma to anyone that can tell me what they would be used for.

Tri-edge · « **Reply #15 on:** October 22, 2008, 01:52:53 PM »

to laminate the motherboard?
EDIT: Oh I see your going to make fpc cables with it.

bustinthejustin · « **Reply #16 on:** October 22, 2008, 02:00:32 PM »

Quote from: Alien_X on October 22, 2008, 01:46:18 AM

okay second update..

I knocked a glass of water off a high shelf onto the motherboard, so my replacement is arriving today.
Secondly, my parts from farnell are arriving today, so I should get it finished ASAP.

I am also picking up a laser printer, and a laminator today. + karma to anyone that can tell me what they would be used for.

To print something out and then laminating it?

MarcusN · « **Reply #17 on:** October 22, 2008, 02:25:41 PM »

Are you going to print out some kind of layout for the d-pad or (X [] /\ O) buttons, laminate it and some how connect this to the mobo?

LaCozTe-2028 · « **Reply #18 on:** October 22, 2008, 07:04:44 PM »

Nice

psp dude i hope you sell these boards im still waithing for you to get on msn alien

Alien_X · « **Reply #19 on:** October 23, 2008, 01:50:50 AM »

Wrong, negative karma to all of you.

To make PCB's.

Okay, UPDATE:

If you can spot the design flaw then + karma

GhoSt · « **Reply #20 on:** October 23, 2008, 01:56:39 AM »

haha so thats what you were soldering. How'd you do one of em in 40 secs, legand. Um is the backlight on the wrong side? Oh and btw sell those and make a fortune.

Alien_X · « **Reply #21 on:** October 23, 2008, 02:20:56 AM »

Quote from: GhoSt_Death on October 23, 2008, 01:56:39 AM

haha so thats what you were soldering. How'd you do one of em in 40 secs, legand. Um is the backlight on the wrong side? Oh and btw sell those and make a fortune.

Yeah backlight is on the wrong side.
I don't think there would be enough interest, I could make one with out the breakout ability much smaller, and neater.
I will move the backlight for version 2 if I make one.
If anyone that seriously wants one would post then I will see.

For this project I will hardwire the backlight.
I have some 6 pin connectors for the backlight (4 pins were out of stock) but sadly they won't fit.

Anyone from the USA want to sell me some 0.8mm Copper Clad?

LaCozTe-2028 · « **Reply #22 on:** October 23, 2008, 02:33:59 PM »

Alien you know what would be sick you buy a board or gr8wrlf and make that psp wall art wireless

MARIOPARTY53 · « **Reply #23 on:** October 23, 2008, 09:56:06 PM »

Quote from: Alien_X on October 19, 2008, 01:00:26 AM

Haha, I guess you could think of it like that.

[insert rude comment about your snesp here]

I wasnt trying to be rude, but ok

Thats stupid, Pswa, so pointless...jk

Whats the point of it? tell me!!

GhoSt · « **Reply #24 on:** October 23, 2008, 10:01:37 PM »

Quote from: MARIOPARTY53 on October 23, 2008, 09:56:06 PM

I wasnt trying to be rude, but ok

Thats stupid, Pswa, so pointless...jk

Whats the point of it? tell me!!

Prototyping! think of how easy it will be. Thats one point of it.

Alien_X · « **Reply #25 on:** October 24, 2008, 12:17:43 AM »

Quote from: LaCozTe-2028 on October 23, 2008, 02:33:59 PM

Alien you know what would be sick you buy a board or gr8wrlf and make that psp wall art wireless

No thanks!!

I am going to try and make a wireless version with quad bi laterals and a PIC.

And yeah, prototyping!

EDIT: Finished, Pics tomorrow

dslitemodder: Please don't double post.

Delete the topic please, If i could delete posts I would..except cyber removed that capabililty by deleting my account and giving me a new account which doesnt have enough posts for that ability.

Alien_X · « **Reply #26 on:** October 26, 2008, 01:34:31 PM »

Finished, See PSPlexiglass
