Author Topic: Scooter (Read 8642 times)

FOOKz™ · « **on:** April 17, 2011, 04:35:11 PM »

This is a POS scooter my friend and I picked up, we're gonna fix it up and get it inspected and road ready.

Summer project: Hes gonna paint it and everything and I'm going to do all the wiring.

Stuff to do:

- Strip it down and take it apart clean/restore everything that isn't broken
- Get rid of rust and old paint and paint it something like dark purple, along the lines of dark blue/black, or lime green.
- New chain and a better gear ratio
- Fresh Brake pads and better brake handles
- Needs a DC Motor controller, Battery, Brake lights, Turn signals, Digital speedometer/Battery meter
- Get it inspected

[ Inspection Checklist ]
http://www.mshp.dps.mo.gov/MSHPWeb/Publications/OtherPublications/documents/SHP-511.pdf

UPDATE #1

whitetop · « **Reply #1 on:** April 17, 2011, 04:38:46 PM »

cannot wait to see this in full working pimped out order my son wants one but he is way to out of control so its a no no for awhile

Rodent · « **Reply #2 on:** April 17, 2011, 04:44:07 PM »

Thats sweet

crazy-modder · « **Reply #3 on:** April 17, 2011, 05:41:49 PM »

Dude rip that electric motor off and figure out a way to hook up a beefed up weed wacker motor

FOOKz™ · « **Reply #4 on:** April 17, 2011, 05:56:00 PM »

LOL i aint even gonna touch a weed wacker motor poopy 2 cycle engines are a waste of money, I would rather not have a loud thing on the scooter rather than a quiet electric motor. The motor is already there and it works.

I have an electric motor at work thats 24v and consumes 15amps and could kick any 40cc weed wacker engine's ass.

[HoP] · « **Reply #5 on:** April 17, 2011, 07:53:05 PM »

Quote from: FOOKz™ on April 17, 2011, 05:56:00 PM

I have an electric motor at work thats 24v and consumes 15amps and could kick any 40cc weed wacker engine's ass.

yes, however you wont be able to just stop at a gas station and charge up in a few seconds...

also:
4 Stroke Weed Eater

you could find something similar also... 4 stroke are becoming more popular!

loboplayero · « **Reply #6 on:** April 17, 2011, 07:56:07 PM »

oh wow its that a mongoose scotter? last mongoose i had was a20" bike

Rodent · « **Reply #7 on:** April 17, 2011, 08:22:11 PM »

I still have my mongoose BMX bike from 1978. and in good condition. stuff we save...lol

DuctTapedGoat · « **Reply #8 on:** April 17, 2011, 08:25:17 PM »

What size electric motor is in there?

FOOKz™ · « **Reply #9 on:** June 10, 2011, 07:23:29 PM »

OK this weekend im planning on getting the chassis sanded down, stripped, and sandblasted. I have pictures on my camera but my SDcard reader is busted (getting one this weekend). So more will be posted soon!...

BTW i picked the color lime green because that was the only good color Home Depot had.

DuctTape: The motor is a 12v POS motor (there no brand name for it, its just a motor LOL)

FOOKz™ · « **Reply #10 on:** July 20, 2011, 12:49:34 PM »

bump for paint.

inspection checklist: http://www.mshp.dps.mo.gov/MSHPWeb/Publications/OtherPublications/documents/SHP-511.pdf

Rodent · « **Reply #11 on:** July 20, 2011, 01:27:49 PM »

LOOKING Good no need to bump ....lol needs another coat and wet sand between coats

FOOKz™ · « **Reply #12 on:** July 20, 2011, 01:29:27 PM »

I haven't taken pictures after the second coat of color and the first wet sand yet. will take more tomorrow. I might go out and grab a couple cans of silver just like you said.

Rodent · « **Reply #13 on:** July 20, 2011, 02:12:39 PM »

Quote from: FOOKz™ on July 20, 2011, 01:29:27 PM

I haven't taken pictures after the second coat of color and the first wet sand yet. will take more tomorrow. I might go out and grab a couple cans of silver just like you said.

So your going to paint a silver base coat then put the lime green?

FOOKz™ · « **Reply #14 on:** July 20, 2011, 02:13:32 PM »

Yeah im just going to sand those first coats so its smooth then put a coat of silver on that and do the rest as green.

Rodent · « **Reply #15 on:** July 20, 2011, 02:14:51 PM »

I think that will bring out the lime green more when you get it all done, and have some depth to the color hope you like the results

FOOKz™ · « **Reply #16 on:** July 26, 2011, 09:21:58 PM »

I de-rusted the handlebars with a bit of hydrochloric acid (nasty stuff but DAMN that works. it also cleaned the concrete it dripped on). The chrome came off with the rust but there's still a thin layer. The trick here is not to remove the nickel coating(acid will). so what im going to do next is take some steel rebar and reverse-electroplate the chrome off with an electrolyte bath of sodium hydroxide 0.5% and sodium carbonate 2% It should take about an hour to get all of the chrome off. This will produce toxic chromium salts that should be disposed properly but I will be using for chrome plating later after all of the excess water is evaporated.

Ordered some N-MOSFET transistors fleabay for the motor controller circuit. I designed the circuit pretty much from scratch and should operate full power at 90% Duty cycle PWM and the motor should not spin at 60% duty cycle PWM. The 555 timer can be tweaked with the trimpot on the inside and the throttle sits on the handlebars. I had put two of the IRF510 transistors in parallel so i could supply 10 Amps of current at peak operation to the motor continuously without fear of overheating. 1N4004 diodes are in reverse to protect the transistors and the rest of the circuits from large reverse voltage spikes when the motor turns into a generator as the scooter goes downhill. (The diode in parallel with the motor will have a chance at catching fire).

The old throttle piece does not work. Last time I measured it I read 7.8K ohms, the reliability of the measurement is negligible no worries there are plenty of spare 7.5K pots i can rip apart and put into the throttle's mechanism.

1TONpete · « **Reply #17 on:** July 27, 2011, 04:22:04 AM »

Can that down hill motion be used to recharge?

FOOKz™ · « **Reply #18 on:** July 27, 2011, 09:01:47 AM »

Quote from: 1TONpete on July 27, 2011, 04:22:04 AM

Can that down hill motion be used to recharge?

yep i would have to be on a steep hill or i would have to have enough momentum to keep going. It would slow me down pretty fast also.

1TONpete · « **Reply #19 on:** July 27, 2011, 09:08:59 AM »

What if it was clutched , so you used it like a "Jake brake"... an engine brake. so like going down hill and such it was used to charge and slow you down.

FOOKz™ · « **Reply #20 on:** July 27, 2011, 10:40:50 AM »

It's supposed to be clutched but the piece is dirty and it spins both ways sometimes. Once i clean it out it will work again.

If i have that piece fixed i won't have to worry about the motor turning into a generator and the problem takes care of itself.

1TONpete · « **Reply #21 on:** July 27, 2011, 12:20:56 PM »

I ment like a manual clutch, you would use like a brake handle. Truckers use whats called Jake brakes in big trucks, just an engine brake, in some hybrid cars they use regenerative breaking which is just the same thing only with electric motors they naturally want to be generators all you have do is regulate the current. I know you of all people should be able to regulate that current to charge when braking. Just an idea thats all. If the part you have wont work , might be something to look into replacing w a common manual clutch.
